CAT5E FTP PATCH CORD

Product Name：

CAT5E FTP Patch Cord

7*0.2mm Cat5e patch cord

FLUKE/CE/ROHS/ISO/TLC

Markets: North America/Eastern Europe/Eastern Asia

Conductor:CU/CCA/CCAG/CCA

7*0.2mm Cat5e patch cord

Conductor:24/26AWG copper,CCA,CCAG,8*7*0.20;8*7*0.16 etcHigh quality

Advanced equipments for both producing and testing

Pass the CEcertificate,ISO9001,etc

1.Conductor:24/26AWG copper,CCA,CCS,8*7*0.12;8*7*0.18 etc

2.Insulation:0.92mm+/-0.06HDPE/PE

3.Pairs:4pairs

4.Shield:PVS,LSNH

5.Temperature Range:-20 up to +75°

6.Conductor Resistance:Max. 9.38 ohm/100m

7.Resistance Unbalance:Max.2%

8.Insulation Resistance:Max. 150 ohm/Km

9.Mutual Capacitance:Max,5600pF/100m

10.Capacitance Unbalance:Max. 330pF/100m

11.Impedance:100+/-15

12.Spark Test:2000V

13.Velocity of propagation:67%

1.LAN Network System

2.Computer Network Distributing System

3.Telecommunication Network System

4.Testing Equipment System

5.CATV System
